INCH-POUND
A-A-52415A(AT)
April 27, 2010
SUPERSEDING
A-A-52415(AT)
January 18, 1993
COMMERCIAL ITEM DESCRIPTION
CLAMP ASSEMBLY - EXHAUST MUFFLER AND TAILPIPE
The General Services Administration has authorized the use of this commercial item
description (CID) as a replacement for MS53041B(AT), which is canceled.
1. SCOPE. This CID covers one type of clamp assembly of many different sizes. Each clamp
assembly consists of two identical clamp halves, two screws, two washers and two nuts.
2. SALIENT CHARACTERISTICS
2.1 Design and construction. The clamp assembly shall be designed and constructed in
accordance with figure 1.
2.2 Materials. The material shall be sheet or strip carbon steel, either hot rolled cold quenched
pickled in oil conforming to ASTM A1011/A1011M or cold rolled temper 2 to 5 conforming to
ASTM A109/A109M. The use of recovered material made in compliance with regulatory
requirements is acceptable providing that all requirements of this CID are met (see 3).
2.3 Identification and marking. Identification and marking shall be permanent and legible and
shall include the manufacturer s identification code (CAGE) and part identification number
(PIN) (see 6.2 and 6.4).
Beneficial comments, recommendations, additions, deletions, clarifications, etc. and any data that
may improve this document should be sent to DAMI_STANDARDIZATION@conus.army.mil or
U.S. Army RDECOM, Tank Automotive Research, Development and Engineering Center,
ATTN: RDTA-EN/STND/TRANS MS #268, 6501 E. 11 Mile Road, Warren, MI 48397-5000.
Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 2990
